Bafang M615 vs M620: Complete Performance Comparison and Guide
The Bafang M620 (Ultra) delivers about 160 Nm of torque, while the M615 (Max) tops out near 120 Nm. If you need maximum hill-climbing grunt for a heavy cargo or fat-tire build, the M620 is the choice. For a lighter, more efficient trail or commuter bike, the M615 often gives you enough power with lower weight. Here is how they compare side-by-side.
At a Glance: M615 vs M620
| Feature | Bafang M615 (Max) | Bafang M620 (Ultra) |
|---|---|---|
| Peak torque | ~120 Nm | ~160 Nm |
| Rated power | 750 W (varies; verify locally) | 1000 W (varies; verify locally) |
| Motor weight | ~5.8 kg (12.8 lbs) | ~6.2 kg (13.7 lbs) |
| Bottom bracket fit | 68–120 mm | 100–120 mm |
| Gear reduction | Planetary + single-stage | Planetary + dual-stage |
| Typical use | Trail, commuter, light cargo | Heavy cargo, fat tire, enduro |
| Peak efficiency cadence | 300–600 RPM | 250–500 RPM |
| Display protocol | CAN | CAN or UART |
Torque and Hill Climbing – Matching Grunt to Grade
The M620’s 160 Nm is the highest torque of any Bafang mid-drive. That extra 40 Nm over the M615 lets you climb sustained 20%+ grades without dropping cadence, even with a 200+ lb payload. Riders towing trailers or hauling weekly groceries up steep hills will feel the M620 maintain speed where the M615 would start to sag.
The M615’s 120 Nm still handles most 10–15% climbs comfortably. It suits a 28–50 lb bike with a rider up to 250 lbs total. Below 10% grade the difference is negligible — both motors spin past 20 mph easily on flat ground.
Concrete takeaway: If your route includes sustained 15%+ grades or your total weight (rider + bike + cargo) exceeds 300 lbs, the M620’s extra torque prevents overheating and speed loss. For moderate hills with lighter loads, the M615 is more than adequate and runs cooler on long climbs.
Weight and Handling – Frame Fit and Ride Feel
The M620 is about 0.4 kg heavier, but that weight sits low and central in the frame. On a fat-tire bike that already weighs 70+ lbs, the difference is invisible. On a trail bike around 45 lbs, the M615 keeps the front end livelier and makes manual handling easier when lifting the wheel over obstacles.
Chainstay clearance is the real constraint. The M620’s larger gear housing requires a 100–120 mm bottom bracket shell, which rules out many standard mountain bike frames. The M615 fits 68–120 mm shells, making it the only option for older commuter frames, standard MTB frames, or conversions on narrower bikes.
Verification step: Measure your frame’s bottom bracket shell width using a caliper, checking at the widest point of the shell where the bearing cups sit. If it measures under 100 mm, the M620 will not fit regardless of bolt pattern or dropouts. Write down the measurement and confirm against the motor’s published shell range before ordering any mounting hardware.
Realistic mismatch: Even if your bottom bracket shell measures 100 mm, the M620’s gear housing can still hit chainstays on frames with tight rear-triangle clearances. Some 100 mm shells from older cargo or tandem frames have ovalized or irregular bores that prevent the M620’s housing from seating flush. Dry-fit a cardboard template or borrow a housing jig before drilling or cutting anything.
Rule of thumb: Use the M615 if your bottom bracket shell is 68–100 mm and you aim to keep total bike weight under 50 lbs. Use the M620 if your frame is already 100+ mm wide and you are building a heavy-duty machine where weight is secondary to pulling power.
Battery and Range – Watt-Hours per Mile Matter
Both motors run on 48V or 52V systems, but the M620 draws higher continuous current (up to 30A vs the M615’s 25A). That difference directly affects range. A 52V 20Ah battery will deliver roughly 10–15% more miles on the M615 because you consume fewer watt-hours per mile at equivalent power output.
On a sustained climb the M620 may consume 18–20 Wh/mile, while the M615 uses 14–16 Wh/mile at the same speed. Plan your battery accordingly: a 48V 14Ah pack (672 Wh) provides about 35 miles of mild assist on the M615, but only 25–28 miles on the M620 under similar climbing conditions.
Concrete mechanism: The M620’s dual-stage gear reduction adds internal friction that becomes a parasitic loss at low power levels. At 200W of assist, the M620 wastes about 8–10% more energy as heat than the M615. That wasted energy comes out of your range.
Practical implication for your next battery purchase: If you are choosing a motor first and then sizing a battery, the M620 forces you into a larger, heavier, and more expensive pack to get the same usable range as an M615 build. A rider commuting 20 miles each way on the M615 can get by with a 48V 14Ah pack. The same commute on the M620 requires at least a 48V 17.5Ah pack (840 Wh) to avoid range anxiety on cold days or headwind stretches. That extra capacity adds roughly 1.5 lbs and $100–$150 to the build cost.
Display and Tuning – CAN vs UART Limits
Both motors accept Bafang’s DPC-18 color display, which allows adjustments to assist levels, wheel size, and speed limit (where legally allowed). The M620 also works with third-party UART displays for custom firmware tuning — useful if you want to program a smoother torque curve, reduce power in certain gears, or fine-tune throttle response.
The M615 is locked to Bafang’s CAN protocol, which limits aftermarket tuning to what the factory display offers. There is no way to flash custom firmware or adjust per-gear power maps.
Practical trade-off: If you plan to tune the motor for different riding conditions — for example, a low-power “slippery” mode for loose gravel or a punchy mode for technical climbs — the M620’s UART flexibility is worth the extra cost. For riders who use stock settings and just want reliable assistance, the M615’s CAN system is simpler and one less thing to troubleshoot.
Decision Framework: Which Motor Fits Your Build
Choose the M620 (Ultra) when:
- You ride a fat-tire, enduro, or cargo bike regularly on 15%+ grades
- Your total system weight (rider + bike + gear) exceeds 330 lbs
- You want aftermarket tuning via UART displays
- Your frame has a 100–120 mm bottom bracket shell
- You accept shorter range per watt-hour in exchange for maximum torque
Choose the M615 (Max) when:
- You are building a lightweight trail, gravel, or commuter e-bike under 50 lbs total
- Your frame uses a 68–100 mm bottom bracket
- You prioritize range and efficiency over raw torque
- You do not need custom firmware or high-current modifications
- You want a simpler system with fewer compatibility concerns
Both are reliable mid-drives with thousands of miles of service life when maintained properly — keep the gearbox oil changed every 2,000 miles and avoid sustained full-throttle climbing at low cadence. The decision comes down to torque demand, frame fit, and whether you need aftermarket tuning. Measure your bottom bracket width, weigh your riding load, and match the motor to the terrain you actually ride, not the one you imagine.
FAQ
Can I upgrade from M615 to M620 later? Yes, but only if your frame has a 100+ mm bottom bracket shell. You will also need a new motor bracket and possibly a wider chainring, and the wiring harness may need replacement if your display protocol differs.
Which motor is more efficient? The M615 is measurably more efficient at moderate power output between 250 and 500W, giving 5–10% more range per watt-hour. The M620 is less efficient at low loads but can handle higher continuous output without overheating.
Are both motors street-legal everywhere? No. The M620’s 1000W rating exceeds Class 1, 2, and 3 limits in many US states. The M615’s 750W rating fits most Class 3 regulations, but local laws vary — verify locally before purchase.
Do I need a special battery for the M620? A 52V battery with at least 25A continuous discharge rating is recommended to avoid voltage sag on steep climbs. Standard 48V 20A batteries will work but may cut out under full load on the M620 during sustained uphill pulls.
